Alteon OS Command Reference
The Information Menu
9343W7774, May 2007
/info/l2/trunk
Trunk Group Information
When trunk groups are configured, you can view the state of each port in the various trunk
groups.
NOTE – If Spanning Tree Protocol on any port in the trunk group is set to forwarding, the
remaining ports in the trunk group will also be set to forwarding.
Role The Role field shows the current role of this port in the Spanning Tree. The
port role can be one of the following: Designated (DESG), Root (ROOT),
Alternate (ALTN), Backup (BKUP), Disabled (DSB), Master (MAST), or
Unknown (UNK).
Designated
Bridge
The Designated Bridge shows information about the bridge connected to
each port, if applicable. Information includes the priority (hex) and MAC
address of the Designated Bridge.
Designated Port The port ID of the port on the Designated Bridge to which this port is con-
nected.
Type Type of link connected to the port, and whether the port is an edge port.
Link type values are AUTO, P2P, or SHARED.
Trunk group 1, port state:
EXT1: STG 1 forwarding
EXT2: STG 1 forwarding
Table 4-21 CIST Parameter Descriptions
Parameter Description
