Alteon OS Command Reference
84
The Information Menu 43W7774, May 2007
The following table describes the IEEE 802.1x parameters.
Table 4-18 802.1x Parameter Descriptions (/info/l2/8021x)
Parameter Description
Port Displays each port’s alias.
Auth Mode Displays the Access Control authorization mode for the port. The Authoriza-
tion mode can be one of the following:
force-unauth
auto
force-auth
Auth Status Displays the current authorization status of the port, either authorized or
unauthorized.
Authenticator
PAE State
Displays the Authenticator Port Access Entity State. The PAE state can be
one of the following:
initialize
disconnected
connecting
authenticating
authenticated
aborting
held
forceAuth
Backend
Auth State
Displays the Backend Authorization State. The Backend Authorization state
can be one of the following:
initialize
request
response
success
fail
timeout
idle
