Alteon OS Command Reference
The Information Menu
8343W7774, May 2007
/info/l2/8021x
802.1x Information
NOTE – The sample screens that appear in this document might differ slightly from the screens
displayed by your system. Screen content varies based on the type of BladeCenter unit that you
are using and the firmware versions and options that are installed.
System capability : Authenticator
System status : disabled
Protocol version : 1
Authenticator Backend
Port Auth Mode Auth Status PAE State Auth State
----- ------------ ------------ -------------- ----------
INT1 force-auth authorized initialize initialize
*INT2 force-auth authorized initialize initialize
*INT3 force-auth authorized initialize initialize
*INT4 force-auth authorized initialize initialize
*INT5 force-auth authorized initialize initialize
*INT6 force-auth authorized initialize initialize
*INT7 force-auth authorized initialize initialize
*INT8 force-auth authorized initialize initialize
INT9 force-auth authorized initialize initialize
INT10 force-auth authorized initialize initialize
*INT11 force-auth authorized initialize initialize
*INT12 force-auth authorized initialize initialize
*INT13 force-auth authorized initialize initialize
*INT14 force-auth authorized initialize initialize
*MGT force-auth authorized initialize initialize
EXT1 force-auth authorized initialize initialize
EXT2 force-auth authorized initialize initialize
*EXT3 force-auth authorized initialize initialize
EXT4 force-auth authorized initialize initialize
------------------------------------------------------------------
* - Port down or disabled
