Alteon OS Command Reference
The Information Menu
8143W7774, May 2007
info/l2/gvrp/gid
Show GID State Machine Information
For each GVRP-registered VLAN, the GID State Machine table indicates the GVRP participa-
tion of switch ports. It also displays the ports’ current Applicant and Registrar states.
Table 4-16 lists the possible GVRP applicant states for the port. The GVRP port’s Applicant
transitions from one state to another as it processes GPDUs.
GID machines for VLAN 10, index 2, gvrp_state: NORMAL
in_use: TRUE - enabled: TRUE
Static ports: empty
Dynamic ports: INT2 EXT4
Combined ports: INT2 EXT4
Port App Reg|Port App Reg|Port App Reg|Port App Reg|Port App Reg|
-------------|-------------|-------------|-------------|-------------|
INT1 - - |INT2 QA INn|INT3 - - |INT4 - - |INT5 - - |
-------------|-------------|-------------|-------------|-------------|
INT6 - - |INT7 - - |INT8 - - |INT9 - - |INT10 - - |
-------------|-------------|-------------|-------------|-------------|
INT11 - - |INT12 - - |INT13 - - |INT14 - - |EXT1 - - |
-------------|-------------|-------------|-------------|-------------|
EXT2 - - |EXT3 - - |EXT4 QA INn|
-------------|-------------|-------------|
Table 4-16 GVRP Port Applicant States
State Description
VA Very anxious, Active member
AA Anxious, Active member
QA Quiet, Active member
LA Leaving, Active member
VP Very anxious, Passive member
AP Anxious, Passive member
QP Quiet, Passive member
VO Very anxious, Observer
AO Anxious, Observer
QO Quiet, Observer
LO Leaving, Observer
