Alteon OS Command Reference
78
The Information Menu 43W7774, May 2007
/info/l2/lacp
Link Aggregation Control Protocol Information
Use these commands to display Link Aggregation Protocol (LACP) status information about
each port on the
GbE Switch Module.
/info/l2/lacp/dump
Show all LACP Information
LACP dump includes the following information for each external port in the GbESM:
lacp
Displays the port’s LACP mode (active, passive, or off)
adminkey
Displays the value of the port’s adminkey.
operkey
Shows the value of the port’s operational key.
[LACP Menu]
aggr - Show LACP aggregator information for the port
port - Show LACP port information
dump - Show all LACP ports information
Table 4-14 LACP Menu Options (/info/l2/lacp)
Command Syntax and Usage
aggr
Displays detailed information of the LACP aggregator used by the selected port.
port
Displays LACP information about the selected port.
dump
Displays a summary of LACP information. For details, see page 78.
port lacp adminkey operkey selected prio attached trunk
aggr
----------------------------------------------------------------
INT1 active 30 30 y 32768 17 19
INT2 active 30 30 y 32768 17 19
INT3 off 19 19 n 32768 -- --
INT4 off 20 20 n 32768 -- --
...
