Alteon OS Command Reference
64
The Information Menu 43W7774, May 2007
/info/sys/snmpv3/group
SNMPv3 Group Table Information
A group is a combination of security model and security name that defines the access rights
assigned to all the security names belonging to that group. The group is identified by a group
name.
/info/sys/snmpv3/comm
SNMPv3 Community Table Information
This command displays the community table information stored in the SNMP engine.
Sec Model User Name Group Name
---------- ------------------------------- --------------------
snmpv1 v1v2only v1v2grp
usm adminmd5 admingrp
usm adminsha admingrp
Table 4-7
SNMPv3 Group Table Information Parameters (/info/sys/snmpv3/group)
Field Description
Sec Model Displays the security model used, which is any one of: USM,
SNMPv1, SNMPv2, and SNMPv3.
User Name Displays the name for the group.
Group Name Displays the access name of the group.
Index Name User Name Tag
---------- ---------- -------------------- ----------
trap1 public v1v2only v1v2trap
Table 4-8 SNMPv3 Community Table Parameters (/info/sys/snmpv3/comm)
Field Description
Index Displays the unique index value of a row in this table
Name Displays the community string, which represents the configuration.
User Name Displays the User Security Model (USM) user name.
Tag
Displays the community tag. This tag specifies a set of transport
endpoints from which a command responder application accepts
management requests and to which a command responder applica-
tion sends an SNMP trap.
