Alteon OS Command Reference
40
First-Time Configuration 43W7774, May 2007
To keep the current setting, press <Enter>.
4. If configuring VLANs, specify a VLAN for the interface.
This prompt appears if you selected to configure VLANs back in Part 1:
Enter the number for the VLAN to which the interface belongs, or press <Enter> without spec-
ifying a VLAN number to accept the current setting.
5. At the prompt, enter y to enable the IP interface, or n to leave it disabled:
6. The system prompts you to configure another interface:
Repeat the steps in this section until all IP interfaces have been configured. When all interfaces
have been configured, press <Enter> without specifying any interface number.
Default Gateways
1. At the prompt, select a default gateway for configuration, or skip default gateway config-
uration:
Enter the number for the default gateway to be configured. To skip default gateway configura-
tion, press <Enter> without typing a gateway number and go to “IP Routing” on page 41.
2. At the prompt, enter the IP address for the selected default gateway:
Enter the IP address in dotted decimal notation, or press <Enter> without specifying an address
to accept the current setting.
Current VLAN: 1
Enter new VLAN [1-4094]:
Enable IP interface? [y/n]
Enter interface number: (1-128)
IP default gateways:
Enter default gateway number: (1-4)
Current IP address: 0.0.0.0
Enter new IP address:
