Alteon OS Command Reference
38
First-Time Configuration 43W7774, May 2007
Setup Part 3: VLANs
If you chose to skip VLANs configuration back in Part 1, skip to “Setup Part 4: IP Configura-
tion” on page 39.
1. Select the VLAN to configure, or skip VLAN configuration at the prompt:
If you wish to change settings for individual VLANs, enter the number of the VLAN you wish
to configure. To skip VLAN configuration, press <Enter> without typing a VLAN number and
go to “Setup Part 4: IP Configuration” on page 39.
2. Enter the new VLAN name at the prompt:
Entering a new VLAN name is optional. To use the pending new VLAN name, press <Enter>.
3. Enter the VLAN port numbers:
Enter each port, by port number or port alias, and confirm placement of the port into this
VLAN. When you are finished adding ports to this VLAN, press <Enter> without specifying
any port.
4. Configure Spanning Tree Group membership for the VLAN:
5. The system prompts you to configure the next VLAN:
VLAN Config:
Enter VLAN number from 2 to 4094, NULL at end:
Current VLAN name: VLAN 2
Enter new VLAN name:
Define Ports in VLAN:
Current VLAN 2: empty
Enter ports one per line, NULL at end:
Spanning Tree Group membership:
Current Spanning Tree Group index: 1
Enter new Spanning Tree Group index [1-127]:
VLAN Config:
Enter VLAN number from 2 to 4094, NULL at end:
