Alteon OS Command Reference
368
Alteon OS SNMP Agent 43W7774, May 2007
Working with Switch Images and
Configuration Files
This section describes how to use MIB calls to work with switch images and configuration
files. You can use a standard SNMP tool to perform the actions, using the MIBs listed in
Table 9-11.
The examples in this section use the MIB name, but you can also use the OID.
Table 9-11 lists the MIBS used to perform operations associated with the GbESM Switch
Image and Configuration files. These MIBS are contained within in the file “aosswitch.mib”
The following SNMP actions can be performed using the MIBs listed in Table 9-11.
Load a new Switch image (boot or running) from a FTP/TFTP server
Load a previously saved switch configuration from a FTP/TFTP server
Save the switch configuration to a FTP/TFTP server
Save a switch dump to a FTP/TFTP server
Table 9-11 MIBs for Switch Image and Configuration Files
MIB Name MIB OID
agTftpServer 1.3.6.1.4.1872.2.5.1.1.7.1.0
agTftpImage 1.3.6.1.4.1872.2.5.1.1.7.2.0
agTftpImageFileName 1.3.6.1.4.1872.2.5.1.1.7.3.0
agTftpCfgFileName 1.3.6.1.4.1872.2.5.1.1.7.4.0
agTftpDumpFileName 1.3.6.1.4.1872.2.5.1.1.7.5.0
agTftpAction 1.3.6.1.4.1872.2.5.1.1.7.6.0
agTftpLastActionStatus 1.3.6.1.4.1872.2.5.1.1.7.7.0
agTftpUserName 1.3.6.1.4.1872.2.5.1.1.7.9.0
agTftpPassword 1.3.6.1.4.1.1872.2.5.1.1.7.10.0
agTftpTSDumpFileName 1.3.6.1.4.1.1872.2.5.1.1.7.11.0
