Alteon OS Command Reference
366
Alteon OS SNMP Agent 43W7774, May 2007
Alteon OS SNMP agent supports the following generic traps as defined in RFC 1215:
ColdStart
WarmStart
LinkDown
LinkUp
AuthenticationFailure
The SNMP agent also supports two Spanning Tree traps as defined in RFC 1493:
NewRoot
TopologyChange
The following are the enterprise SNMP traps supported in Alteon OS:
Table 9-10 Alteon OS-Supported Enterprise SNMP Traps
Trap Name Description
altSwPrimaryPowerSupplyFailure Signifies that the primary power supply failed.
altSwFanFailure Signifies that the fan has failed.
altSwDefGwUp Signifies that the default gateway is alive.
altSwDefGwDown Signifies that the default gateway is down.
altSwDefGwInService Signifies that the default gateway is up and in service
altSwDefGwNotInService Signifies that the default gateway is alive but not in
service
altSwVrrpNewMaster
The newMaster trap indicates that the sending agent has tran-
sitioned to 'Master' state.
altSwVrrpNewBackup The newBackup trap indicates that the sending agent has
transitioned to 'Backup' state.
altSwVrrpAuthFailure
A vrrpAuthFailure trap signifies that a packet has been
received from a router whose authentication key or authenti-
cation type conflicts with this router's authentication key or
authentication type. Implementation of this trap is optional.
altSwLoginFailure
A altSwLoginFailure trap signifies that someone failed to
enter a valid username/password combination.
