Alteon OS Command Reference
344
The Maintenance Menu 43W7774, May 2007
/maint/debug
Debugging Options
The Miscellaneous Debug Menu displays trace buffer information about events that can be
helpful in understanding switch operation. You can view the following information using the
debug menu:
Events traced by the Management Processor (MP)
Events traced to a buffer area when a reset occurs
If the switch resets for any reason, the MP trace buffer is saved into the snap trace buffer area.
The output from these commands can be interpreted by IBM Service Support.
[Miscellaneous Debug Menu]
tbuf - Show MP trace buffer
snap - Show MP snap (or post-mortem) trace buffer
clrcfg - Clear all flash configs
Table 9-4 Miscellaneous Debug Menu Options (/maint/debug)
Command Syntax and Usage
tbuf
Displays the Management Processor trace buffer. Header information similar to the following is shown:
MP trace buffer at 13:28:15 Fri May 25, 2001; mask: 0x2ffdf748
The buffer information is displayed after the header.
snap
Displays the Management Processor snap (or post-mortem) trace buffer. This buffer contains infor-
mation traced at the time that a reset occurred.
clrcfg
Deletes all flash configuration blocks.
