Alteon OS Command Reference
336
The Boot Options Menu 43W7774, May 2007
Selecting a Configuration Block
When you make configuration changes to the GbE Switch Module, you must save the changes so
that they are retained beyond the next time the switch is reset. When you perform the save
command, your new configuration changes are placed in the active configuration block. The
previous configuration is copied into the backup configuration block.
There is also a factory configuration block. This holds the default configuration set by the factory
when your
GbE Switch Module was manufactured. Under certain circumstances, it may be desir-
able to reset the switch configuration to the default. This can be useful when a custom-configured
GbE Switch Module is moved to a network environment where it will be re configured for a differ-
ent purpose.
Use the following procedure to set which configuration block you want the switch to load the
next time it is reset:
1. At the Boot Options# prompt, enter:
2. Enter the name of the configuration block you want the switch to use:
The system informs you of which configuration block is currently set to be loaded at the next
reset, and prompts you to enter a new choice:
Boot Options# conf
Currently set to use active configuration block on next reset.
Specify new block to use ["active"/"backup"/"factory"]:
