Alteon OS Command Reference
The Boot Options Menu
33543W7774, May 2007
Uploading a Software Image from Your Switch
You can upload a software image from the switch to a FTP or TFTP server.
1. At the Boot Options# prompt, enter:
2. The system prompts you for information. Enter the desired image:
3. Enter the name or the IP address of the FTP or TFTP server:
4. Enter the name of the file into which the image will be uploaded on the FTP or TFTP
server:
5. The system then requests confirmation of what you have entered. To have the file
uploaded, enter Y.
Boot Options# ptimg
Enter name of switch software image to be uploaded
["image1"|"image2"|"boot"]: <image>
<hostname or server-IP-addr> <server-file-
name>
Enter hostname or IP address of FTP/TFTP server: <name or IP address>
Enter name of file on FTP/TFTP server: <filename>
image2 currently contains Software Version 1.0.1.0
Upload will transfer image2 (1889411 bytes) to file "test"
on TFTP server 192.1.1.1.
Confirm upload operation [y/n]: y
