Alteon OS Command Reference
First-Time Configuration
3343W7774, May 2007
Starting Setup When You Log In
The Setup prompt appears automatically whenever you login as the system administrator under
the factory default settings.
1. Connect to the switch.
After connecting, the login prompt will appear as shown below.
2. Enter admin as the default administrator password.
If the factory default configuration is detected, the system prompts:
NOTE – If the default admin login is unsuccessful, or if the administrator Main Menu appears
instead, the system configuration has probably been changed from the factory default settings.
If you are certain that you need to return the switch to its factory default settings, see “Select-
ing a Configuration Block” on page 336.
3. Enter
y to begin the initial configuration of the switch, or n to bypass the Setup facility.
Enter Password:
10Gb Uplink Ethernet Switch Module
18:44:05 Wed Jan 3, 2007
The switch is booted with factory default configuration.
To ease the configuration of the switch, a "Set Up" facility which
will prompt you with those configuration items that are essential to
the operation of the switch is provided.
Would you like to run "Set Up" to configure the switch? [y/n]:
