Alteon OS Command Reference
318
The Configuration Menu 43W7774, May 2007
/cfg/acl/group <ACL Group number>
ACL Group Configuration
This menu allows you to compile one or more ACLs into an ACL Group. Once you create an
ACL Group, you can assign the ACL Group to one or more ports.
reset
Resets Packet Format parameters for the ACL to their default values.
cur
Displays the current Packet Format parameters for the ACL.
[ACL Group 1 Menu]
add - Add ACL to group
rem - Remove ACL from group
cur - Display current ACL items in group
Table 6-112 ACL Group Menu Options (/cfg/acl/group x)
Command Syntax and Usage
add acl <1-896>
Adds the selected ACL to the ACL Group.
rem acl <1-896>
Removes the selected ACL from the ACL Group.
cur
Displays the current ACL group parameters.
Table 6-111 ACL Packet Format Filtering Menu Options (/cfg/acl/acl x/pktfmt)
Command Syntax and Usage
