Alteon OS Command Reference
The Configuration Menu
31743W7774, May 2007
/cfg/acl/acl <ACL number>/re-mark/outprof
Re-Marking Out-of-Profile Configuration
/cfg/acl/acl <ACL number>/pktfmt
Packet Format Filtering Configuration
This menu allows you to define Packet Format matching criteria for an ACL.
[Re-marking - Out Of Profile Menu]
updscp - Set the update DSCP
reset - reset update DSCP setting
cur - Display current settings
Table 6-110 ACL Re-Mark Out-of-Profile Menu (/cfg/acl/acl x/re-mark/outprof)
Command Syntax and Usage
updscp <0-63>
Sets the DiffServ Code Point (DSCP) of Out-of-Profile packets to the selected value. The switch
sets the DSCP value on Out-of-Profile packets.
reset
Resets the update DSCP parameters for Out-of-Profile packets to their default values.
cur
Displays current Re-Mark Out-of-Profile parameters.
[Filtering Packet Format Menu]
ethfmt - Set to filter on ethernet format
tagfmt - Set to filter on ethernet tagging format
ipfmt - Set to filter on IP format
reset - Reset all fields
cur - Display current parameters
Table 6-111 ACL Packet Format Filtering Menu Options (/cfg/acl/acl x/pktfmt)
Command Syntax and Usage
ethfmt eth2|SNAP|LLC
Defines the Ethernet format for the ACL.
tagfmt none|tagged
Defines the tagging format for the ACL.
ipfmt none|v4|v6
Defines the IP format for the ACL.
