Alteon OS Command Reference
The Configuration Menu
31343W7774, May 2007
/cfg/acl/acl <ACL number>/meter
ACL Metering Configuration
This menu defines the metering profile for the selected ACL.
reset
Resets the TCP/UDP parameters for the ACL to their default values.
cur
Displays the current TCP/UDP Filtering parameters.
[Metering Menu]
cir - Set committed rate in KiloBits/s
mbsize - Set maximum burst size in KiloBits
enable - Enable/disable port metering
dpass - Set to Drop or Pass out of profile traffic
reset - Reset meter parameters
cur - Display current settings
Table 6-106 ACL Metering Menu Options (/cfg/acl/acl x/meter)
Command Syntax and Usage
cir <64-10000000>
Configures the committed rate, in Kilobits per second. The committed rate must be a multiple
of 64.
mbsize <32-4096>
Configures the maximum burst size, in Kilobits. Enter one of the following values for
mbsize: 32, 64, 128, 256, 512, 1024, 2048, 4096
enable e|d
Enables or disables metering on the ACL.
dpass drop|pass
Configures the ACL Meter to either drop or pass out-of-profile traffic.
reset
Reset ACL Metering parameters to their default values.
cur
Displays current ACL Metering parameters.
Table 6-105 TCP/UDP Filtering Menu Options (/cfg/acl/acl x/tcpudp)
Command Syntax and Usage
