Alteon OS Command Reference
312
The Configuration Menu 43W7774, May 2007
/cfg/acl/acl <ACL number>/tcpudp
TCP/UDP Filtering Configuration
This menu allows you to define TCP/UDP matching criteria for an ACL.
[Filtering TCP/UDP Menu]
sport - Set to filter on TCP/UDP source port
dport - Set to filter on TCP/UDP destination port
flags - Set to filter TCP/UDP flags
reset - Reset all fields
cur - Display current parameters
Table 6-105 TCP/UDP Filtering Menu Options (/cfg/acl/acl x/tcpudp)
Command Syntax and Usage
sport <source port (1-65535)> <mask (0xFFFF)>
Defines a source port for the ACL. If defined, traffic with the specified TCP or UDP source port
will match this ACL. Specify the port number. Listed below are some of the well-known ports:
Number
Name
20 ftp-data
21 ftp
22 ssh
23 telnet
25 smtp
37 time
42 name
43 whois
53 domain
69 tftp
70 gopher
79 finger
80 http
dport <destination port (1-65535)> <mask (0xFFFF)>
Defines a destination port for the ACL. If defined, traffic with the specified TCP or UDP destina-
tion port will match this ACL. Specify the port number, just as with sport above.
flags <value (0x0-0x3f)>
Defines a TCP/UDP flag for the ACL.
