Alteon OS Command Reference
308
The Configuration Menu 43W7774, May 2007
/cfg/acl/acl <ACL number>
ACL Configuration
These menus allow you to define filtering criteria for each Access Control List (ACL).
[ACL 1 Menu]
ethernet - Ethernet Header Options Menu
ipv4 - IP Header Options Menu
tcpudp - TCP/UDP Header Options Menu
meter - ACL Metering Configuration Menu
re-mark - ACL Re-mark Configuration Menu
pktfmt - Set to filter specific packet format types
egrport - Set to filter for packets egressing this port
action - Set filter action
stats - Enable/disable statistics for this acl
reset - Reset filtering parameters
cur - Display current filter configuration
Table 6-102 ACL Menu Options (/cfg/acl/acl x)
Command Syntax and Usage
ethernet
Displays the ACL Ethernet Header menu. To view menu options, see page 309.
ipv4
Displays the ACL IP Header menu. To view menu options, see page 310.
tcpudp
Displays the ACL TCP/UDP Header menu. To view menu options, see page 312.
meter
Displays the ACL Metering menu. To view menu options, see page 313.
re-mark
Displays the ACL Re-mark menu. To view menu options, see page 314.
pktfmt <packet format>
Displays the ACL Packet Format menu. To view menu options, see page 317.
egrport <port alias or number>
Configures the ACL to function on egress packets.
action permit|deny|setprio <0-7>
Configures a filter action for packets that match the ACL definitions. You can choose to permit
(pass) or deny (drop) packets, or set the 802.1p priority level (0-7).
