Alteon OS Command Reference
The Configuration Menu
30343W7774, May 2007
/cfg/l3/vrrp/track
VRRP Tracking Configuration
This menu is used for setting weights for the various criteria used to modify priority levels dur-
ing the master router election process. Each time one of the tracking criteria is met (see “VRRP
Virtual Router Priority Tracking Menu” on page 298), the priority level for the virtual router is
increased by an amount defined through this menu.
NOTE – These priority tracking options only define increment values. These options do not
affect the VRRP master router election process until options under the VRRP Virtual Router
Priority Tracking Menu (see page 298) are enabled.
[VRRP Tracking Menu]
vrs - Set priority increment for virtual router tracking
ifs - Set priority increment for IP interface tracking
ports - Set priority increment for VLAN switch port tracking
cur - Display current VRRP Priority Tracking configuration
Table 6-97 VRRP Tracking Menu Options (/cfg/l3/vrrp/track)
Command Syntax and Usage
vrs <0-254>
Defines the priority increment value (0 through 254) for virtual routers in master mode detected on
this switch. The default value is 2.
ifs <0-254>
Defines the priority increment value (0 through 254) for active IP interfaces detected on this
switch. The default value is 2.
ports <0-254>
Defines the priority increment value (0 through 254) for active ports on the virtual router’s VLAN.
The default value is 2.
cur
Displays the current configuration of priority tracking increment values.
