Alteon OS Command Reference
302
ī The Configuration Menu 43W7774, May 2007
/cfg/l3/vrrp/if <interface number>
VRRP Interface Configuration
NOTE ā The interface-number (1 to 127) represents the IP interface on which authentication
parameters must be configured.
This menu is used for configuring VRRP authentication parameters for the IP interfaces used
with the virtual routers.
[VRRP Interface 1 Menu]
auth - Set authentication types
passw - Set plain-text password
del - Delete interface
cur - Display current VRRP interface configuration
Table 6-96 VRRP Interface Menu Options (/cfg/l3/vrrp/if)
Command Syntax and Usage
auth none|password
Defines the type of authentication that will be used: none (no authentication), or password
(password authentication).
passw <password>
Defines a plain text password up to eight characters long. This password will be added to each
VRRP packet transmitted by this interface when password authentication is chosen (see auth
above).
del
Clears the authentication configuration parameters for this IP interface. The IP interface itself is
not deleted.
cur
Displays the current configuration for this IP interfaceās authentication parameters.
