Alteon OS Command Reference
The Configuration Menu
30143W7774, May 2007
/cfg/l3/vrrp/group/track
Virtual Router Group Priority Tracking Configuration
NOTE – If Virtual Router Group Tracking is enabled, then the tracking option will be available
only under group option. The tracking setting for the other individual virtual routers will be
ignored.
[Virtual Router Group Priority Tracking Menu]
ifs - Enable/disable tracking other interfaces
ports - Enable/disable tracking VLAN switch ports
cur - Display current VRRP Group Tracking configuration
Table 6-95 Virtual Router Group Priority Tracking Menu (/cfg/l3/vr/group/track)
Command Syntax and Usage
ifs disable|enable
When enabled, the priority for this virtual router will be increased for each other IP interface active
on this switch. An IP interface is considered active when there is at least one active port on the
same VLAN. This helps elect the virtual routers with the most available routes as the master. This
command is disabled by default.
ports disable|enable
When enabled, the priority for this virtual router will be increased for each active port on the same
VLAN. A port is considered “active” if it has a link and is forwarding traffic. This helps elect the
virtual routers with the most available ports as the master. This command is disabled by default.
cur
Displays the current configuration for priority tracking for this virtual router.
