Alteon OS Command Reference
286
The Configuration Menu 43W7774, May 2007
/cfg/l3/igmp/mrtr <Mrouter number>
IGMP Relay Multicast Router Configuration
Table 6-85 describes the commands used to configure the IGMP Relay multicast router.
dis
Disables IGMP Relay.
cur
Displays the current IGMP Relay configuration.
[Multicast router 2 Menu]
addr - Set IP address of multicast router
intr - Set interval between ping attempts
retry - Set number of failed attempts to declare router DOWN
restr - Set number of successful attempts to declare router UP
version - Set IGMP version
ena - Enable multicast router
dis - Disable multicast router
del - Delete multicast router
cur - Display current multicast router configuration
Table 6-83 IGMP Relay Mrouter Menu Options (/cfg/l3/igmp/relay/mrtr)
Command Syntax and Usage
addr <IP address (such as 224.0.1.0)>
Configures the IP address of the IGMP multicast router used for IGMP Relay.
intr <1-60>
Configures the time interval between ping attempts to the upstream Mrouters, in seconds.
The default value is 2.
retry <1-120>
Configures the number of failed ping attempts required before the switch declares this Mrouter is
down. The default value is 4.
restr <1-128>
Configures the number of successful ping attempts required before the switch declares this
Mrouter is up. The default value is 5.
version <1-2>
Configures the IGMP version (1 or 2) of the multicast router.
Table 6-82 IGMP Relay Menu Options (/cfg/l3/igmp/relay)
Command Syntax and Usage
