Alteon OS Command Reference
274
The Configuration Menu 43W7774, May 2007
/cfg/l3/ospf/redist fixed|static|rip|ebgp|ibgp
OSPF Route Redistribution Configuration
delete
Deletes OSPF host entry.
cur
Displays the current OSPF host entries.
[OSPF Redistribute Fixed Menu]
add - Add rmap into route redistribution list
rem - Remove rmap from route redistribution list
export - Export all routes of this protocol
cur - Display current route-maps added
Table 6-73 OSPF Route Redistribution Menu Options (/cfg/l3/ospf/redist)
Command Syntax and Usage
add (<route map (1-32)> <route map (1-32)>)... |all
Adds selected routing maps to the rmap list.To add all the 32 route maps, enter all. To add spe-
cific route maps, enter routing map numbers one per line, NULL at the end.
This option adds a route map to the route redistribution list. The routes of the redistribution proto-
col matched by the route maps in the route redistribution list will be redistributed.
rem (<route map (1-32)> <route map (1-32)>) ... |all
Removes the route map from the route redistribution list.
Removes routing maps from the rmap list. To remove all 32 route maps, enter all. To remove
specific route maps, enter routing map numbers one per line, NULL at end.
export <metric (1-16777214)><metric type [
1|2]> |none
Exports the routes of this protocol as external OSPF AS-external LSAs in which the metric and
metric type are specified. To remove a previous configuration and stop exporting the routes of the
protocol, enter none.
cur
Displays the current route map settings.
Table 6-72 OSPF Host Entry Configuration Menu Options (/cfg/l3/ospf/host)
Command Syntax and Usage
