Alteon OS Command Reference
26
The Command Line Interface 43W7774, May 2007
Accessing the Switch
To enable better switch management and user accountability, three levels or classes of user
access have been implemented on the
GbE Switch Module. Levels of access to CLI, Web man-
agement functions, and screens increase as needed to perform various switch management
tasks. Conceptually, access classes are defined as follows:
User interaction with the switch is completely passive—nothing can be changed on the
GbE Switch Module. Users may display information that has no security or privacy implica-
tions, such as switch statistics and current operational state information.
Operators can make temporary changes on the
GbE Switch Module. These changes are lost
when the switch is rebooted/reset. Operators have access to the switch management fea-
tures used for daily switch operations. Because any changes an operator makes are undone
by a reset of the switch, operators cannot severely impact switch operation.
Administrators are the only ones that may make permanent changes to the switch configu-
ration—changes that are persistent across a reboot/reset of the switch. Administrators can
access switch functions to configure and troubleshoot problems on the
GbE Switch Module.
Because administrators can also make temporary (operator-level) changes as well, they
must be aware of the interactions between temporary and permanent changes.
Access to switch functions is controlled through the use of unique surnames and passwords.
Once you are connected to the switch via local Telnet, remote Telnet, or SSH, you are
prompted to enter a password. The default user names/password for each access level are listed
in the following table.
NOTE – It is recommended that you change default switch passwords after initial configuration
and as regularly as required under your network security policies. For more information, see
“Setting Passwords” on page 43.
Table 1-2 User Access Levels
User Account Description and Tasks Performed Password
User The User has no direct responsibility for switch management.
He or she can view all switch status information and statistics,
but cannot make any configuration changes to the switch.
user
Operator The Operator manages all functions of the switch. The
Operator can reset ports, except the management port.
oper
