Alteon OS Command Reference
The Configuration Menu
25943W7774, May 2007
/cfg/l3/rmap <route map number>
Routing Map Configuration
NOTE – The map number (1-32) represents the routing map you wish to configure.
Routing maps control and modify routing information.
[IP Route Map 1 Menu]
alist - Access List number
aspath - AS Filter Menu
ap - Set as-path prepend of the matched route
lp - Set local-preference of the matched route
metric - Set metric of the matched route
type - Set OSPF metric-type of the matched route
prec - Set the precedence of this route map
weight - Set weight of the matched route
enable - Enable route map
disable - Disable route map
delete - Delete route map
cur - Display current route map configuration
Table 6-62 Routing Map Menu Options (/cfg/l3/rmap)
Command Syntax and Usage
alist <number 1-8>
Displays the Access List menu. For more information, see page 261.
aspath <number 1-8>
Displays the Autonomous System (AS) Filter menu. For more information, see page 262.
ap <AS number> [<AS number>] [<AS number>]|none
Sets the AS path preference of the matched route. One to three path preferences can be configured.
lp <(0-4294967294)>|none
Sets the local preference of the matched route, which affects both inbound and outbound direc-
tions. The path with the higher preference is preferred.
metric <(1-4294967294)>|none
Sets the metric of the matched route.
type <value (
1|2)>|none
Assigns the type of OSPF metric. The default is type 1.
Type 1—External routes are calculated using both internal and external metrics.
Type 2—External routes are calculated using only the external metrics. Type 1 routes have
more cost than Type 2.
none—Removes the OSPF metric.
