Alteon OS Command Reference
250
The Configuration Menu 43W7774, May 2007
/cfg/l3/if <interface number>
IP Interface Configuration
The GbE Switch Module can be configured with up to 128 IP interfaces. Each IP interface repre-
sents the
GbE Switch Module on an IP subnet on your network. The Interface option is disabled
by default.
NOTE – To maintain connectivity between the management module and the GbE Switch Mod-
ule, use the management module interface to change the IP address of the switch.
[IP Interface 1 Menu]
addr - Set IP address
mask - Set subnet mask
vlan - Set VLAN number
relay - Enable or disable BOOTP relay
ena - Enable interface
dis - Disable interface
del - Delete interface
cur - Display current interface configuration
Table 6-54 IP Interface Menu Options (/cfg/l3/if)
Command Syntax and Usage
addr <IP address (such as 192.4.17.101)>
Configures the IP address of the switch interface using dotted decimal notation.
mask <IP subnet mask (such as 255.255.255.0)>
Configures the IP subnet address mask for the interface using dotted decimal notation.
vlan <VLAN number (1-4095)>
Configures the VLAN number for this interface. Each interface can belong to one VLAN, though
any VLAN can have multiple IP interfaces in it.
relay disable|enable
Enables or disables the BOOTP relay on this interface. It is enabled by default.
ena
Enables this IP interface.
dis
Disables this IP interface.
