Alteon OS Command Reference
244
The Configuration Menu 43W7774, May 2007
NOTE – All ports must belong to at least one VLAN. Any port which is removed from a VLAN
and which is not a member of any other VLAN is automatically added to default VLAN 1. You
cannot remove a port from VLAN 1 if the port has no membership in any other VLAN.
Also, you cannot add a port to more than one VLAN unless the port has VLAN tagging turned
on (see the tag command on page 209).
def <list of port numbers>
Defines which ports are members of this VLAN. Every port must be a member of at least one
VLAN. By default, internal server ports (INTx) and external ports (EXTx) are in VLAN 1.
ena
Enables this VLAN.
dis
Disables this VLAN without removing it from the configuration.
del
Deletes this VLAN.
cur
Displays the current VLAN configuration.
Table 6-50 VLAN Configuration Menu Options (/cfg/l2/vlan)
Command Syntax and Usage
