/cfg/l2/vlan <VLAN number>
VLAN Configuration
The commands in this menu configure VLAN attributes, change the status of each VLAN,
change the port membership of each VLAN, and delete VLANs. For more information on con-
figuring VLANs, see “Setup Part 3: VLANs” on page 38.
By default, the VLAN menu option is disabled except VLAN 1, which is enabled all the time.
Internal server ports (INTx) and external ports (EXTx) are in VLAN 1 by default. Up to 1024
VLANs can be configured on the GbESM.
[VLAN 1 Menu]
pvlan - Protocol VLAN Menu
privlan - Private-VLAN Menu
name - Set VLAN name
stg - Assign VLAN to a Spanning Tree Group
add - Add port to VLAN
rem - Remove port from VLAN
def - Define VLAN as list of ports
ena - Enable VLAN
dis - Disable VLAN
del - Delete VLAN
cur - Display current VLAN configuration
Table 6-50 VLAN Configuration Menu Options (/cfg/l2/vlan)
Command Syntax and Usage
pvlan <1-8>
Displays the Protocol-based VLAN menu. To view menu options, see page 245.
privlan
Displays the Private VLAN menu. To view menu options, see page 247.
name
Assigns a name to the VLAN or changes the existing name. The default VLAN name is the first
one.
stg <Spanning Tree Group index [1-128]>
Assigns a VLAN to a Spanning Tree Group.
add <port alias or number>
Adds port(s) to the VLAN membership.
rem <port alias or number>
Removes port(s) from this VLAN.
