Alteon OS Command Reference
The Configuration Menu
23943W7774, May 2007
/cfg/l2/lacp/port <port alias or number>
LACP Port Configuration
Use the following commands to configure Link Aggregation Control Protocol (LACP) for the
selected port.
[LACP Port EXT1 Menu]
mode - Set LACP mode
prio - Set LACP port priority
adminkey - Set LACP port admin key
cur - Display current LACP port configuration
Table 6-46 LACP Port Menu Options (/cfg/l2/lacp/port)
Command Syntax and Usage
mode off|active|passive
Set the LACP mode for this port, as follows:
off
Turn LACP off for this port. You can use this port to manually configure a static trunk. The
default value is off.
active
Turn LACP on and set this port to active. Active ports initiate LACPDUs.
passive
Turn LACP on and set this port to passive. Passive ports do not initiate LACPDUs, but respond
to LACPDUs from active ports.
prio <1-65535>
Sets the priority value for the selected port. Lower numbers provide higher priority. Default is
32768.
adminkey <1-65535>
Set the admin key for this port. Only ports with the same admin key and oper key (operational state
generated internally) can form a LACP trunk group.
cur
Displays the current LACP configuration for this port.
