Alteon OS Command Reference
238
The Configuration Menu 43W7774, May 2007
/cfg/l2/lacp
LACP Configuration
Use the following commands to configure Link Aggregation Control Protocol (LACP) for the
GbESM.
[LACP Menu]
sysprio - Set LACP system priority
timeout - Set LACP system timeout scale for timing out partner
info
port - LACP port Menu
cur - Display current LACP configuration
Table 6-45 LACP Menu Options (/cfg/l2/lacp)
Command Syntax and Usage
sysprio <1-65535>
Defines the priority value (1 through 65535) for the GbESM. Lower numbers provide higher prior-
ity. The default value is 32768.
timeout short|long
Defines the timeout period before invalidating LACP data from a remote partner. Choose short
(3 seconds) or long (90 seconds). The default value is long.
Note: It is recommended that you use a timeout value of long, to reduce LACPDU processing. If
your GbESM’s CPU utilization rate remains at 100% for periods of 90 seconds or more, consider
using static trunks instead of LACP.
port <port alias or number>
Displays the LACP Port menu. To view menu options, see page 239.
cur
Display current LACP configuration.
