Alteon OS Command Reference
236
The Configuration Menu 43W7774, May 2007
/cfg/l2/thash
IP Trunk Hash Configuration
Use the following commands to configure IP trunk hash settings for the GbESM.
/cfg/l2/thash/set
IP Trunk Hash
Trunk hash parameters are set globally for the GbE Switch Module. You can enable one or two
parameters, to configure any of the following valid combinations:
SMAC (source MAC only)
DMAC (destination MAC only)
SIP (source IP only)
DIP (destination IP only)
SIP + DIP (source IP and destination IP)
SMAC + DMAC (source MAC and destination MAC)
[IP Trunk Hash Menu]
set - IP Trunk Hash Settings Menu
cur - Display current IP trunk hash configuration
Table 6-43 IP Trunk Hash Menu Options (/cfg/l2/thash)
Command Syntax and Usage
set
Displays the Trunk Hash Settings menu. To view menu options, see page 236.
cur
Display current trunk hash configuration.
[set IP Trunk Hash Settings Menu]
smac - Enable/disable smac hash
dmac - Enable/disable dmac hash
sip - Enable/disable sip hash
dip - Enable/disable dip hash
cur - Display current trunk hash setting
