Alteon OS Command Reference
The Configuration Menu
23543W7774, May 2007
/cfg/l2/trunk <trunk group number>
Trunk Configuration
Trunk groups can provide super-bandwidth connections between GbE Switch Modules or other
trunk capable devices. A trunk is a group of ports that act together, combining their bandwidth
to create a single, larger port. Up to 11 trunk groups can be configured on the
GbE Switch Mod-
ule
, with the following restrictions:
Any physical switch port can belong to no more than one trunk group.
Up to four ports/trunks can belong to the same trunk group.
Configure all ports in a trunk group with the same link configuration (speed, duplex, flow
control).
Trunking from non-Alteon devices must comply with Cisco
®
EtherChannel
®
technology.
By default, each trunk group is empty and disabled.
[Trunk group 1 Menu]
add - Add port to trunk group
rem - Remove port from trunk group
ena - Enable trunk group
dis - Disable trunk group
del - Delete trunk group
cur - Display current Trunk Group configuration
Table 6-42 Trunk Configuration Menu Options (/cfg/l2/trunk)
Command Syntax and Usage
add <port alias or number>
Adds a physical port to the current trunk group.
rem <port alias or number>
Removes a physical port from the current trunk group.
ena
Enables the current trunk group.
dis
Disables the current trunk group.
del
Removes the current trunk group configuration.
cur
Displays current trunk group parameters.
