Alteon OS Command Reference
224
The Configuration Menu 43W7774, May 2007
/cfg/l2/mrst/cist/brg
CIST Bridge Configuration
CIST bridge parameters are used only when the switch is in MSTP or RSTP mode. CIST
parameters do not affect operation of STP/PVST+.
[CIST Bridge Menu]
prior - Set CIST bridge Priority (0-65535)
mxage - Set CIST bridge Max Age (6-40 secs)
fwd - Set CIST bridge Forward Delay (4-30 secs)
cur - Display current CIST bridge parameters
Table 6-35 CIST Bridge Configuration Menu Options (/cfg/l2/mrst/cist/brg)
Command Syntax and Usage
prior <0-65535>
Configures the CIST bridge priority. The bridge priority parameter controls which bridge on the
network is the MSTP root bridge. To make this switch the root bridge, configure the bridge priority
lower than all other switches and bridges on your network. The lower the value, the higher the
bridge priority. The range is 0 to 65535, and the default is 32768.
mxage <6-40 seconds>
Configures the CIST bridge maximum age. The maximum age parameter specifies the maximum
time the bridge waits without receiving a configuration bridge protocol data unit before it reconfig-
ures the MSTP network. The range is 6 to 40 seconds, and the default is 20 seconds.
fwd <4-30 seconds>
Configures the CIST bridge forward delay parameter. The forward delay parameter specifies the
amount of time that a bridge port has to wait before it changes from the listening state to the learn-
ing state and from the learning state to the forwarding state. The range is 4 to 30 seconds, and the
default is 15 seconds.
cur
Displays the current CIST bridge configuration.
