Alteon OS Command Reference
The Configuration Menu
21343W7774, May 2007
/cfg/l2
Layer 2 Configuration
[Layer 2 Menu]
8021x - 802.1x Menu
mrst - Multiple Spanning Tree/Rapid Spanning Tree Menu
stg - Spanning Tree Menu
gvrp - GVRP configuration menu
trunk - Trunk Group Menu
thash - IP Trunk Hash Menu
lacp - Link Aggregation Control Protocol Menu
failovr - Failover Menu
vlan - VLAN Menu
upfast - Enable/disable Uplink Fast
update - UplinkFast station update rate
bpdugrd - Enable/disable BPDU Guard
macnotif - Enable/disable MAC address notification
cur - Display current layer 2 parameters
Table 6-28 Layer 2 Configuration Menu (/cfg/l2)
Command Syntax and Usage
8021x
Displays the 802.1x Configuration Menu. To view menu options, see page 215.
mrst
Displays the Rapid Spanning Tree/Multiple Spanning Tree Protocol Configuration Menu. To view
menu options, see page 221.
stg <group number [1-128]>
Displays the Spanning Tree Configuration Menu. To view menu options, see page 227.
gvrp
Displays the Generic VLAN Registration Protocol (GVRP) Menu. To view menu options, see
page 233.
trunk <trunk group number (1-11)>
Displays the Trunk Group Configuration Menu. To view menu options, see page 235.
thash
Displays the IP Trunk Hash Menu. To view menu options, see page 236.
lacp
Displays the Link Aggregation Control Protocol Menu. To view menu options, see page 238.
failovr
Displays the Failover Configuration Menu. To view menu options, see page 240.
