Alteon OS Command Reference
210
The Configuration Menu 43W7774, May 2007
learn disable|enable
Enables or disables FDB learning on the port.
tag disable|enable
Disables or enables VLAN tagging for this port. It is disabled by default.
tagpvid disable|enable
Disables or enables VLAN tag persistence. When disabled, the VLAN tag is removed from pack-
ets whose VLAN tag matches the port PVID. The default value is disabled for INT and EXT
ports, and enabled for MGT ports.
fastfwd disable|enable
Disables or enables Port Fast Forwarding, which permits a port that participates in Spanning
Tree to bypass the Listening and Learning states and enter directly into the Forwarding state.
While in the Forwarding state, the port listens to the BPDUs to learn if there is a loop and, if
dictated by normal STG behavior (following priorities, etc.), the port transitions into the Blocking
state. This feature permits the GbESM to interoperate well within Rapid Spanning Tree networks.
floodblk disable|enable
Enables or disables port Flood Blocking. When enabled, unicast and multicast packets with
unknown destination MAC addresses are blocked from the port.
ena
Enables the port.
dis
Disables the port. (To temporarily disable a port without changing its configuration attributes, refer
to “Temporarily Disabling a Port” on page 212.)
cur
Displays current port parameters.
Table 6-25 Port Configuration Menu (/cfg/port)
Command Syntax and Usage
