Alteon OS Command Reference
200
The Configuration Menu 43W7774, May 2007
/cfg/sys/ssnmp/snmpv3/tparam
SNMPv3 Target Parameters Table Configuration
You can configure the target parameters entry and store it in the target parameters table in the
SNMP engine. This table contains parameters that are used to generate a message. The param-
eters include the message processing model (for example: SNMPv3, SNMPv2c, SNMPv1), the
security model (for example: USM), the security name, and the security level (noAuthno-
Priv, authNoPriv, or authPriv).
[SNMPv3 snmpTargetParamsTable 1 Menu]
name - Set target params name
mpmodel - Set message processing model
model - Set security model
uname - Set USM user name
level - Set minimum level of security
del - Delete targetParamsTable entry
cur - Display current targetParamsTable configuration
Table 6-17 Target Parameters Table Configuration Menu Options (/cfg/sys/
ssnmp/snmpv3/tparam)
Command Syntax and Usage
name <32 character name>
Allows you to configure the locally arbitrary, but unique identifier that is associated with this entry.
mpmodel snmpv1|snmpv2c|snmpv3
Allows you to configure the message processing model that is used to generate SNMP messages.
model usm|snmpv1|snmpv2
Allows you to select the security model to be used when generating the SNMP messages.
uname <32 character name>
Defines the name that identifies the user in the USM table (page 193) on whose behalf the SNMP
messages are generated using this entry.
level noAuthNoPriv|authNoPriv|authPriv
Allows you to select the level of security to be used when generating the SNMP messages using
this entry. The level noAuthNoPriv means that the SNMP message will be sent without authen-
tication and without using a privacy protocol. The level authNoPriv means that the SNMP mes-
sage will be sent with authentication but without using a privacy protocol. The authPriv means
that the SNMP message will be sent both with authentication and using a privacy protocol.
del
Deletes the targetParamsTable entry.
cur
Displays the current targetParamsTable configuration.
