Alteon OS Command Reference
192
The Configuration Menu 43W7774, May 2007
comm <snmpCommunity number [1-16]>
The community table contains objects for mapping community strings and version-independent
SNMP message parameters. To view menu options, see page 198.
taddr <snmpTargetAddr number [1-16]>
This command allows you to configure destination information, consisting of a transport domain
and a transport address. This is also termed as transport endpoint. The SNMP MIB provides a
mechanism for performing source address validation on incoming requests, and for selecting com-
munity strings based on target addresses for outgoing notifications. To view menu options, see
page 199.
tparam
<target params index [1-16]>
This command allows you to configure SNMP parameters, consisting of message processing
model, security model, security level, and security name information. There may be multiple trans-
port endpoints associated with a particular set of SNMP parameters, or a particular transport end-
point may be associated with several sets of SNMP parameters. To view menu options, see
page 200.
notify <notify index [1-16]>
A notification application typically monitors a system for particular events or conditions, and gen-
erates Notification-Class messages based on these events or conditions. To view menu options, see
page 201.
v1v2 disable|enable
This command allows you to enable or disable the access to SNMP version 1 and version 2. This
command is enabled by default.
cur
Displays the current SNMPv3 configuration.
Table 6-10 SNMPv3 Configuration Menu Options (/cfg/sys/ssnmp/snmpv3)
