Alteon OS Command Reference
180
The Configuration Menu 43W7774, May 2007
/cfg/sys/radius
RADIUS Server Configuration
[RADIUS Server Menu]
prisrv - Set primary RADIUS server address
secsrv - Set secondary RADIUS server address
secret - Set RADIUS secret
secret2 - Set secondary RADIUS server secret
port - Set RADIUS port
retries - Set RADIUS server retries
timeout - Set RADIUS server timeout
telnet - Enable or disable RADIUS backdoor for telnet
on - Turn RADIUS authentication ON
off - Turn RADIUS authentication OFF
cur - Display current RADIUS configuration
Table 6-5 System Configuration Menu Options (/cfg/sys/radius)
Command Syntax and Usage
prisrv <IP address>
Sets the primary RADIUS server address.
secsrv <IP address>
Sets the secondary RADIUS server address.
secret <1-32 character secret>
This is the shared secret between the switch and the RADIUS server(s).
secret2 <1-32 character secret>
This is the secondary shared secret between the switch and the RADIUS server(s).
port <RADIUS port configure, default 1645>
Enter the number of the UDP port to be configured, between 1500 - 3000. The default is 1645.
retries <RADIUS server retries (1-3)>
Sets the number of failed authentication requests before switching to a different RADIUS server.
The default is 3 requests.
timeout <RADIUS server timeout seconds (1-10)>
Sets the amount of time, in seconds, before a RADIUS server authentication attempt is considered
to have failed. The default is 3 seconds.
telnet disable|enable
Enables or disables the RADIUS backdoor for telnet. The telnet command also applies to
SSH/SCP connections and the Browser-Based Interface (BBI). The default is disabled.
To obtain the RADIUS backdoor password for your GbESM, contact your IBM Service and
Support line.
on
Enables the RADIUS server.
