Alteon OS Command Reference
176
The Configuration Menu 43W7774, May 2007
ssnmp
Displays the System SNMP Menu. To view menu options, see page 189.
access
Displays the System Access Menu. To view menu options, see page 202.
date
Prompts the user for the system date. The date reverts to its default value when the switch is reset.
time
Configures the system time using a 24-hour clock format. The time reverts to its default value
when the switch is reset.
timezone
Configures the time zone where the switch resides. You are prompted to select your location (con-
tinent, country, region) by the timezone wizard. Once a region is selected, the switch updates the
time to reflect local changes to Daylight Savings Time, etc.
olddst enable|disable
Enables or disables use of the Daylight Saving Time (DST) rules in effect prior to the year 2007.
The default value is disabled.
idle <idle timeout in minutes>
Sets the idle timeout for CLI sessions, from 1 to 60 minutes. The default is 5 minutes.
notice <max 1024 char multi-line login notice> <'-' to end>
Displays login notice immediately before the “Enter password:” prompt. This notice can contain
up to 1024 characters and new lines.
bannr <string, maximum 80 characters>
Configures a login banner of up to 80 characters. When a user or administrator logs into the switch,
the login banner is displayed. It is also displayed as part of the output from the /info/sys com-
mand.
hprompt disable|enable
Enables or disables displaying of the host name (system administrator’s name) in the Command
Line Interface (CLI).
reminder disable|enable
Enables or disables reminder messages in the CLI. The default value is enabled.
cur
Displays the current system parameters.
Table 6-2 System Configuration Menu Options (/cfg/sys)
Command Syntax and Usage
