Alteon OS Command Reference
The Statistics Menu
16143W7774, May 2007
/stats/mp/pkt
MP Packet Statistics
Packet counts:
allocs: 1722684 frees: 1722684
mediums: 0 mediums hi-watermark: 4
jumbos: 0 jumbos hi-watermark: 0
smalls: 0 smalls hi-watermark: 8
failures: 0
Table 5-27 Packet Statistics (/stats/mp/pkt)
Statistics Description
allocs Total number of packet allocations from the packet buffer pool by the
TCP/IP protocol stack.
frees Total number of times the packet buffers are freed (released) to the packet
buffer pool by the TCP/IP protocol stack.
mediums Total number of packet allocations with size between 128 to 1536 bytes
from the packet buffer pool by the TCP/IP protocol stack.
mediums hi-water-
mark
The highest number of packet allocation with size between 128 to 1536
bytes from the packet buffer pool by the TCP/IP protocol stack.
jumbos Total number of packet allocations with more than 1536 bytes from the
packet buffer pool by the TCP/IP protocol stack.
jumbos hi-watermark The highest number of packet allocation with more than 1536 bytes from
the packet buffer pool by the TCP/IP protocol stack.
smalls Total number of packet allocations with size less than 128 bytes from the
packet buffer pool by the TCP/IP protocol stack.
smalls hi-watermark The highest number of packet allocation with size less than 128 bytes
from the packet buffer pool by the TCP/IP protocol stack.
failures Total number of packet allocation failures from the packet buffer pool by
the TCP/IP protocol stack.
