Alteon OS Command Reference
158
The Statistics Menu 43W7774, May 2007
/stats/l3/vrrp
VRRP Statistics
Virtual Router Redundancy Protocol (VRRP) support on the GbE Switch Module provides
redundancy between routers in a LAN. This is accomplished by configuring the same virtual
router IP address and ID number on each participating VRRP-capable routing device. One of
the virtual routers is then elected as the master, based on a number of priority criteria, and
assumes control of the shared virtual router IP address. If the master fails, one of the backup
virtual routers will assume routing authority and take control of the virtual router IP address.
When virtual routers are configured, you can display protocol statistics for VRRP:
The statistics for the VRRP LAN are displayed:
VRRP statistics:
vrrpInAdvers: 0 vrrpBadAdvers: 0
vrrpOutAdvers: 0
vrrpBadVersion: 0 vrrpBadVrid: 0
vrrpBadAddress: 0 vrrpBadData: 0
vrrpBadPassword: 0 vrrpBadInterval: 0
Table 5-25 VRRP Statistics (/stats/l3/vrrp)
Statistics Description
vrrpInAdvers The total number of valid VRRP advertisements that have been received.
vrrpBadAdvers The total number of VRRP advertisements received that were dropped.
vrrpOutAdvers The total number of VRRP advertisements that have been sent.
vrrpBadVersion The total number of VRRP advertisements received that had a bad version
number.
vrrpBadVrid The total number of VRRP advertisements received that had a bad virtual
router ID.
vrrpBadAddress The total number of VRRP advertisements received that had a bad address.
vrrpBadData The total number of VRRP advertisements received that had bad data.
vrrpBadPassword The total number of VRRP advertisements received that had a bad password.
vrrpBadInterval The total number of VRRP advertisements received that had a bad interval.
