Alteon OS Command Reference
The Statistics Menu
15743W7774, May 2007
Intf Change Stats:
hello The sum total number of Hello packets sent on all interfaces and areas.
down The sum total number of interfaces down in all OSPF areas.
loop The sum total of interfaces no longer connected to the attached network
across all OSPF areas and interfaces.
unloop The sum total number of interfaces, connected to the attached network in
all OSPF areas.
wait timer The sum total number of times the Wait Timer has been fired, indicating
the end of the waiting period that is required before electing a (Backup)
Designated Router across all OSPF areas and interfaces.
backup The sum total number of Backup Designated Routers on the attached net-
work for all OSPF areas and interfaces.
nbr change The sum total number of changes in the set of bidirectional neighbors
associated with any interface across all OSPF areas.
Timers Kickoff:
hello The sum total number of times the Hello timer has been fired (which trig-
gers the send of a Hello packet) across all OPSF areas and interfaces.
retransmit The sum total number of times the Retransmit timer has been fired across
all OPSF areas and interfaces.
lsa lock The sum total number of times the Link State Advertisement (LSA) lock
timer has been fired across all OSPF areas and interfaces.
lsa ack The sum total number of times the LSA Ack timer has been fired across
all OSPF areas and interfaces.
dbage The total number of times the data base age (Dbage) has been fired.
summary The total number of times the Summary timer has been fired.
ase export The total number of times the Autonomous System Export (ASE) timer
has been fired.
Table 5-24 OSPF General Statistics (stats/l3/ospf/general) (Continued)
Statistics Description
