Alteon OS Command Reference
156
The Statistics Menu 43W7774, May 2007
Nbr Change Stats:
hello The sum total of all Hello packets received from neighbors on all OSPF
areas and interfaces.
Start The sum total number of neighbors in this state (that is, an indication that
Hello packets should now be sent to the neighbor at intervals of Hel-
loInterval seconds.) across all OSPF areas and interfaces.
n2way The sum total number of bidirectional communication establishment
between this router and other neighboring routers.
adjoint ok The sum total number of decisions to be made (again) as to whether an
adjacency should be established/maintained with the neighbor across all
OSPF areas and interfaces.
negotiation done The sum total number of neighbors in this state wherein the Master/slave
relationship has been negotiated, and sequence numbers have been
exchanged, across all OSPF areas and interfaces.
exchange done The sum total number of neighbors in this state (that is, in an adjacency's
final state) having transmitted a full sequence of Database Description
packets, across all OSPF areas and interfaces.
bad requests The sum total number of Link State Requests which have been received
for a link state advertisement not contained in the database across all
interfaces and OSPF areas.
bad sequence The sum total number of Database Description packets which have been
received that either:
a) Has an unexpected DD sequence number
b) Unexpectedly has the init bit set
c) Has an options field differing from the last Options field
received in a Database Description packet.
Any of these conditions indicate that some error has occurred during
adjacency establishment for all OSPF areas and interfaces.
loading done The sum total number of link state updates received for all out-of-date
portions of the database across all OSPF areas and interfaces.
n1way The sum total number of Hello packets received from neighbors, in which
this router is not mentioned across all OSPF interfaces and areas.
rst_ad The sum total number of times the Neighbor adjacency has been reset
across all OPSF areas and interfaces.
down The total number of Neighboring routers down (that is, in the initial
state of a neighbor conversation.) across all OSPF areas and interfaces.
Table 5-24 OSPF General Statistics (stats/l3/ospf/general) (Continued)
Statistics Description
