Alteon OS Command Reference
152
The Statistics Menu 43W7774, May 2007
/stats/l3/igmp <VLAN number>
IGMP Statistics
This menu option displays statistics about the use of the IGMP Multicast Groups.
IGMP statistics are described in the following table:
IGMP Snoop vlan 2 statistics:
-----------------------------------------------------------------------
rxIgmpValidPkts: 0 rxIgmpInvalidPkts: 0
rxIgmpGenQueries: 0 rxIgmpGrpSpecificQueries: 0
rxIgmpGroupSrcSpecificQueries: 0
rxIgmpLeaves: 0 rxIgmpReports: 0
txIgmpReports: 0 txIgmpGrpSpecificQueries: 0
txIgmpLeaves: 0 rxIgmpV3CurrentStateRecords: 0
rxIgmpV3SourceListChangeRecords:0 rxIgmpV3FilterChangeRecords: 0
Table 5-22 IGMP Statistics (/stats/l3/igmp)
Statistic Description
rxIgmpValidPkts
Total number of valid IGMP packets received
rxIgmpInvalidPkts
Total number of invalid packets received
rxIgmpGenQueries
Total number of General Membership Query
packets received
rxIgmpGrpSpecificQueries
Total number of Membership Query packets
received from specific groups
rxIgmpGroupSrcSpecificQueries
Total number of Group Source-Specific Queries
(GSSQ) received
rxIgmpLeaves
Total number of Leave requests received
rxIgmpReports
Total number of Membership Reports received
txIgmpReports
Total number of Membership reports transmitted
txIgmpGrpSpecificQueries
Total number of Membership Query packets
transmitted to specific groups
txIgmpLeaves
Total number of Leave messages transmitted
rxIgmpV3CurrentStateRecords
Total number of Current State records received
rxIgmpV3SourceListChangeRecords
Total number of Source List Change records
received.
rxIgmpV3FilterChangeRecords
Total number of Filter Change records received.
