Alteon OS Command Reference
The Statistics Menu
14743W7774, May 2007
icmpInDestUnreachs The number of ICMP Destination Unreachable messages received.
icmpInTimeExcds The number of ICMP Time Exceeded messages received.
icmpInParmProbs The number of ICMP Parameter Problem messages received.
icmpInSrcQuenchs The number of ICMP Source Quench (buffer almost full, stop send-
ing data) messages received.
icmpInRedirects The number of ICMP Redirect messages received.
icmpInEchos The number of ICMP Echo (request) messages received.
icmpInEchoReps The number of ICMP Echo Reply messages received.
icmpInTimestamps The number of ICMP Timestamp (request) messages received.
icmpInTimestampReps The number of ICMP Timestamp Reply messages received.
icmpInAddrMasks The number of ICMP Address Mask Request messages received.
icmpInAddrMaskReps The number of ICMP Address Mask Reply messages received.
icmpOutMsgs The total number of ICMP messages which this entity (the switch)
attempted to send. Note that this counter includes all those counted
by icmpOutErrors.
icmpOutErrors The number of ICMP messages which this entity (the switch) did not
send due to problems discovered within ICMP such as a lack of
buffer. This value should not include errors discovered outside the
ICMP layer such as the inability of IP to route the resultant data-
gram. In some implementations there may be no types of errors that
contribute to this counter's value.
icmpOutDestUnreachs The number of ICMP Destination Unreachable messages sent.
icmpOutTimeExcds The number of ICMP Time Exceeded messages sent.
icmpOutParmProbs The number of ICMP Parameter Problem messages sent.
icmpOutSrcQuenchs The number of ICMP Source Quench (buffer almost full, stop send-
ing data) messages sent.
icmpOutRedirects The number of ICMP Redirect messages sent. For a host, this object
will always be zero, since hosts do not send redirects.
icmpOutEchos The number of ICMP Echo (request) messages sent.
icmpOutEchoReps The number of ICMP Echo Reply messages sent.
Table 5-19 ICMP Statistics (/stats/l3/icmp)
Statistics Description
