Alteon OS Command Reference
The Statistics Menu
14543W7774, May 2007
/stats/l3/route
Route Statistics
/stats/l3/arp
ARP statistics
This menu option enables you to display Address Resolution Protocol statistics.
Route statistics:
ipRoutesCur: 11 ipRoutesHighWater: 11
ipRoutesMax: 2048
Table 5-16 Route Statistics (/stats/l3/route)
Statistics Description
ipRoutesCur The total number of outstanding routes in the route table.
ipRoutesHighWater The highest number of routes ever recorded in the route table.
ipRoutesMax The maximum number of routes that are supported.
ARP statistics:
arpEntriesCur: 3 arpEntriesHighWater: 4
arpEntriesMax: 4095
Table 5-17 ARP Statistics (/stats/l3/arp)
Statistics Description
arpEntriesCur The total number of outstanding ARP entries in the ARP table.
arpEntriesHighWater The highest number of ARP entries ever recorded in the ARP table.
arpEntriesMax The maximum number of ARP entries that are supported.
