Alteon OS Command Reference
The Statistics Menu
14143W7774, May 2007
/stats/l3
Layer 3 Statistics
The Layer 3 statistics provided by each menu option are briefly described in Table 5-14, with
pointers to detailed information.
[Layer 3 Statistics Menu]
geal3 - GEA Layer 3 Stats Menu
ip - Show IP stats
route - Show route stats
arp - Show ARP stats
dns - Show DNS stats
icmp - Show ICMP stats
tcp - Show TCP stats
udp - Show UDP stats
igmp - Show IGMP stats
ospf - OSPF stats
vrrp - Show VRRP stats
clrvrrp - Clear VRRP stats
rip - Show RIP stats
igmpgrps - Total number of IGMP groups
ipmcgrps - Total number of IPMC groups
clrigmp - Clear IGMP stats
ipclear - Clear IP stats
dump - Dump layer 3 stats
Table 5-14 Layer 3 Statistics Menu Options (/stats/l3)
Command Syntax and Usage
geal3
Displays the Gigabit Ethernet Aggregators (GEA) statistics menu. GEA statistics are used by ser-
vice and support personnel.
ip
Displays IP statistics. See page 143 for sample output.
route
Displays route statistics. See page 145 for sample output.
arp
Displays Address Resolution Protocol (ARP) statistics. See page 145 for sample output.
dns
Displays Domain Name System (DNS) statistics. See page 146 for sample output.
