Alteon OS Command Reference
The Statistics Menu
13943W7774, May 2007
/stats/l2/gvrp
GVRP Statistics
Generic VLAN Registration Protocol (GVRP) statistics are described in the following table:
GARP/GVRP statistics
====================
Join Empty received: 3194
Join In received: 492
Empty received: 482
Leave In received: 0
Leave Empty received: 0
Leave All received: 138
Join Empty transmitted: 1461
Join In transmitted: 586
Empty transmitted: 1175
Leave In transmitted: 0
Leave Empty transmitted: 0
Leave All transmitted: 143
Unaccepted Attribute Value: 0
Invalid Message/Attributes: 0
Failure in registration: 0
Table 5-13 GVRP Statistics (/stats/gvrp)
Statistic Description
Join Empty received The total number of Join Empty messages received.
Join In received The total number of Join In messages received.
Empty received The total number of Empty messages received.
Leave In received The total number of Leave In messages received.
Leave Empty
received
The total number of Leave Empty messages received.
Leave All received The total number of Leave All messages received.
Join Empty trans-
mitted
The total number of Join Empty messages sent.
Join In transmitted The total number of Join In messages sent.
Empty transmitted The total number of Empty messages sent.
Leave In transmit-
ted
The total number of Leave In messages sent.
