Alteon OS Command Reference
138
The Statistics Menu 43W7774, May 2007
/stats/l2/lacp <port alias or number>
LACP Statistics
Link Aggregation Control Protocol (LACP) statistics are described in the following table:
Port EXT1:
--------------------------------------
Valid LACPDUs received: - 870
Valid Marker PDUs received: - 0
Valid Marker Rsp PDUs received: - 0
Unknown version/TLV type: - 0
Illegal subtype received: - 0
LACPDUs transmitted: - 6031
Marker PDUs transmitted: - 0
Marker Rsp PDUs transmitted: - 0
Table 5-12 LACP Statistics (/stats/lacp)
Statistic Description
Valid LACPDUs
received
Total number of valid LACP data units received.
Valid Marker PDUs
received
Total number of valid LACP marker data units received.
Valid Marker Rsp
PDUs received
Total number of valid LACP marker response data units received.
Unknown version/TLV
type
Total number of LACP data units with an unknown version or type,
length, and value (TLV) received.
Illegal subtype
received
Total number of LACP data units with an illegal subtype received.
LACPDUs transmitted Total number of LACP data units transmitted.
Marker PDUs trans-
mitted
Total number of LACP marker data units transmitted.
Marker Rsp PDUs
transmitted
Total number of LACP marker response data units transmitted.
